Weihai Medison Medical Equipment Co.,Ltd

Product Model: MAX400-A1

Product Composition: vacuum pump, control circuit, battery, display, shell, solution collection bottle, and switching power supply.

Applicable Scope: vacuum drainage therapy for wound

Product Remark: Certificate No. of Medical Equipment

Production License: Lu FDA Production License 20080075

Product Description：

* With ultra-low negative pressure design (-50mmHg to -450mmHg), it is continuously adjustable.

* With super-smart design and various operating mode, it is more practical.

* With stable performance and long life, it can maintain more than 10,000 hours of continuous operation.

* The carefully designed muffler system controls running noise of the device in a very low range (less than 45 dB), which does not affect the patient's rest.

* With microcomputer chip controlled, it has high accuracy and user-friendly operation interface.

* Its intelligent memory system can automatically record the parameters and modes in the last setup, free from repeatedly setting after each starting up.

* LCD digital display makes it convenient for user to adjust and operate.

* Multiple safety power supply solutions:

Product performance:

1. Adjustable scope: 10mmHg;

2. Negative pressure range: -50 mmHg -450 mmHg; pressure display error: +0.2%;

3. Suction flow: 1.5L/min ~ 10L/min;

4. Time adjustment: time error +5%;

5. Noise: not more than 45Db;

6. External power supply: 12V 5A DC switch power (medically certified); the host, DC powered , has no risk of electric shock;

7. Operation status: continuous and intermittent.

Contraindications:

1. Debridement undone or wound with the necrotic eschar;

2. Wound with tumor tissue;

3. Sinus connected with the organs;

4. Wound with great vessels or organs exposed.
